Overhead Aerial OPGW Fiber Optic Cable 12 Core Single Mode Uni-Tube

Ask Lasest Price
Brand Name :	YUANTONG
Model Number :	OPGW
Certification :	ISO,ANATEL,ROSH,TLC，CCC
Price :	usd 5.5
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	100km per week
Delivery Time :	within 7 working days

Add to Cart

Product Details
Company Profile

Overhead Aerial OPGW Fiber Optic Cable 12 Core Single Mode Uni-Tube

Optical Fiber Composite Ground Wire 12 Core Single Mode Uni-Tube Overhead Aerial Opgw Cable

Description:

Optical fiber composite overhead phase conductor(oppc) is a new type of special power composite cable, which combines optical fiber unit and traditional phase structure in the wire, it makes full use of its own line power system resources, particularly the power system resources, particularly the power distribution network system, to avoid conflict with the outside world in aspects such as frequency resources, routing coordination, electromagnetic compatibility, which gives it dual functions of power transmission and communication.

Application:

Optical fiber composite ground wire [OPGW] is suitable for installation on new power lines with double function of ground wire and communication. Especially for installation on normal voitage and extra high voltage power lines. OPGW can replace conventional ground wire of old power line with increasing fiber communication function. They conduct short circuit current and provide lightning resistance.

Cable characteristics:

1. Up to 144 fibers

2. Cable diameter and weight approximate with another ground wire. Less additional load to tower, high tensile strength.

3. Excellent stainless steel tube stranding technology make the fibers have good secondary excess length and allow the fibers free movement in the tube. Which keeps the fiber stress-free while the cable is subjected to longitudinal stress.

4. Optical fibers are protected by stainless steel tubes.

5. Excellent security, good bullet resist performance.

6. ACSW, AAW and SST stranded design provide wide range combination of electrical conductivity and mechanical tensile strength.

NO.	Subject	Unit	Technical parameter
1	Optic fiber type	/	G.652D
2	Numbers of optic fiber cores	Cores	96/128
3	Attenuation characteristics	1310nm(dB/km)	≤0.35
3	Attenuation characteristics	1550nm(dB/km)	≤0.22
4	Cable external diameter	mm	≤12.8
5	Weight per unit length of optic cable	kg/km	≤502
6	Total cross section	mm²	79.38
6	Cross section of aluminum clad steel wire	mm²	79.38
7	Rate tensile strength RTS	kN	62.0
8	Elastic modulus	GPa	132
9	Linear expansion coefficient	×10-6/℃	13.8
10	20℃ DC resistance	Ω/km	≤0.740
11	Shortcut current(0.5s,20℃～200℃)	kA	9.21
12	Allowable short circuit current capacity (0.5s,20℃～200℃)	kA².S	≥42.4
13	Maximum allowable temperature	℃	200
14	Maximum allowable tension(40%RTS)	kN	24.80
15	Annual average operatingtension(25%RTS)	kN	15.50
16	Minimum allowable bending radius	operation:mm	15D
16	Minimum allowable bending radius	construction:mm	20D
17	Storage installation temperature	Storage(℃)	-40～+80
17	Storage installation temperature	Installation(℃)	-10～+50

Overhead Aerial OPGW Fiber Optic Cable 12 Core Single Mode Uni-Tube
