Single Mode 2 Core G657A LSZH Fiber Optic Outdoor FTTH Drop Cable

Ask Lasest Price
Brand Name :	YUANTONG
Model Number :	FTTH Drop Cable-2 Core
Certification :	ROSH ,TLC, CCC, ISO
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union, D/P
Supply Ability :	500km per week
Delivery Time :	7 days

Add to Cart

Product Details
Company Profile

Single Mode 2 Core G657A LSZH Fiber Optic Outdoor FTTH Drop Cable

Single Mode 2 Core G657A LSZH Outdoor Fiber Optic FTTH Drop Cable

Description
The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP) are placed at the two sides. A steel wire as the additional strength member is also applied. Then the cable is completed with a black or color LSZH sheath,There is a recognition guide at the bottom of the cable.

Features

Adopted to indoor distribution.
As pigtail of communication equipment
Suitable for communication equipment servrd
Can be installed conveniently and perated simply

Fiber parameter:

No.	Items			Unit	Specification
					G.657A1
1	Mode Field Diameter		1310nm	μm	9.0±0.4
			1550nm	μm	10.1±0.5
2	Cladding Diameter			μm	124.8±0.7
3	Cladding Non-Circularity			%	≤0.7
4	Core-Cladding Concentricity Error			μm	≤0.5
5	Coating Diameter			μm	245±5
6	Coating Non-Circularity			%	≤6.0
7	Cladding-Coating Concentricity Error			μm	≤12.0
8	Cable Cutoff Wavelength			nm	λcc≤1260
9	Attenuation(max.)		1310nm	dB/km	≤0.35
			1550nm	dB/km	≤0.21
10	Macro-Bending Loss	1turn×10mm radius @1550nm		dB	≤0.75
		1turn×10mm radius @1625nm		dB	≤1.5

Mechanical and Environmental for 2 core g657a LSZH outdoor drop fiber optic cable ftt

Items	Unite	Specifications
Tension(Long Term)	N	100
Tension(Short Term)	N	200
Crush(Long Term)	N/10cm	1000
Crush(Short Term)	N/10cm	2200
Min. Bend Radius(Dynamic)	mm	20D
Min. Bend Radius(Static)	mm	5D
Operating Temperature	℃	–20~+60
Storage Temperature	℃	–20~+60

FAQ
1. Are you the real manufacturer?
Yes. We are the real manufacturer with 18 years' history.

2. What is your fiber brand ?
Corning, SEI, YOFC, FiberHome, etc

3. Can you accept small order?
Yes, small order is available .We support new project of our customers as we know business is always from small order.

4.What is your warranty period?
25 years for fiber optic cable

5. Which kind of certification you have ?
ISO9001, SGS, 3C Anatel.

6. What is your delivery time?
Usually within 2-3 working days

7. What about your annual production capacity?
Outdoor/Indoor Fiber Optic Cable, our annual output is 8,000,000 KM;
FTTH/FTTX/FTTA Cable, it is 6,000,000 KM per year;
Patch Cord/Pigtails, it is 12,400,000 Pieces per year.

8. What is your payment way?
T/T, L/C, Western Union and Paypal.

9. Can you supply customized products and logo?
-Yes. We supply OEM&ODM service. You can send us your drawing.

10. Can you supply your cable test value form?
-Yes. After finishing production , we can supply if you ask.

11. Do your factory inspect every roll of cables?
-Yes. we factory do 100% inspection per order.
