GMDKAU-2B6-2.6-BL Ultralight Armored Field Optical Cable

Ask Lasest Price
Brand Name :	YUANTONG
Model Number :	GMDKAU-2B6
Certification :	ROSH ,TLC, CCC, ISO
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union, D/P
Supply Ability :	500 Kilometer/Kilometers per Month
Delivery Time :	7 days

Add to Cart

Product Details
Company Profile

GMDKAU-2B6-2.6-BL Ultralight Armored Field Optical Cable

GMDKAU-2B6-2.6-BL ultralight Armored Field Optical Cable

Description

The ultra-light armored field optical duplex cable is an armored communication optical cable specially designed for temporary rapid wiring and repeated retractable and retractable operations in the field and complex environments of the army. The optical cable adheres to the design concept of "light", "tough" and "soft", and is armored with ultra-micro stainless steel hose, high-modulus aramid and elastic wear-resistant TPU outer sheath, which makes it have Very good mechanical properties. The biggest feature of this kind of optical cable is light weight and high mechanical strength, which is suitable for rapid wiring or repeated retraction and release of military field communication systems; radar, aviation and ship wiring; oil fields, mines, ports, live TV broadcasts, communication line repairs, etc. harsh conditions.

Feature

◆ Ultra-small stainless steel hose protection, with good mechanical properties;
◆ Large-area and high-modulus Kevlar reinforcement makes the optical cable reach a tensile strength of more than 1500N;
◆ The thermoplastic polyurethane elastomer sheath provides the optical cable with good structural stability, wear resistance, oil resistance, low temperature flexibility and other properties;
◆ Adopt special anti-bending optical fiber, so that the optical cable can be bent arbitrarily, which is convenient to use;
◆Small outer diameter of 2.6mm, the weight does not exceed 9kg/km

Usage

Military communications;
Communication of coal mines, oil wells, natural gas, geological exploration, etc.
Broadcast TV broadcast, temporary communication system

Transmission Performance

General specification for GJB1428B-2009 optical cable

Technical parameters (typical value)

Core Number	Optical Cable Specification(mm)	Tensile Strength		Crush-Resistance(N/100mm)		Minimum Bending Radius(mm)		Optical Cable Weight (kg/km)
Core Number	Optical Cable Specification(mm)	Short-term	Long-term	Short-term	Long-term	Dynamic	Static	Optical Cable Weight (kg/km)
1-2	2.6	1200	1500	4000	5000	30D	10D	8.5
4-6	3.0	1300	1800	3500	4500	30D	10D	9-9.2
8	3.5	1500	2000	3500	4500	30D	10D	9.5

Note:

1. represents the outer diameter of the short shaft.

2. The typical value can be correspondingly adjusted according to actual conditions.

3. The corresponding products can be designed according to client' s special requirements.

FAQ
1. Are you the real manufacturer?
Yes. We are the real manufacturer with 18 years' history.

2. What is your fiber brand ?
Corning, SEI, YOFC, FiberHome, etc

3. Can you accept small order?
Yes, small order is available .We support new project of our customers as we know business is always from small order.

4.What is your warranty period?
25 years for fiber optic cable

5. Which kind of certification you have ?
ISO9001, SGS, 3C Anatel.

6. What is your delivery time?
Usually within 2-3 working days

7. What about your annual production capacity?
Outdoor/Indoor Fiber Optic Cable, our annual output is 8,000,000 KM;
FTTH/FTTX/FTTA Cable, it is 6,000,000 KM per year;
Patch Cord/Pigtails, it is 12,400,000 Pieces per year.

8. What is your payment way?
T/T, L/C, Western Union and Paypal.

9. Can you supply customized products and logo?
-Yes. We supply OEM&ODM service. You can send us your drawing.

10. Can you supply your cable test value form?
-Yes. After finishing production , we can supply if you ask.

11. Do your factory inspect every roll of cables?
-Yes. we factory do 100% inspection per order.
