Direct Burial 144 Core Fiber Optic Outdoor Cable Anti-Rodent Steel Tape Armor Fibre Cable GYTS

    Buy cheap Direct Burial 144 Core Fiber Optic Outdoor Cable Anti-Rodent Steel Tape Armor Fibre Cable GYTS from wholesalers

    Buy cheap Direct Burial 144 Core Fiber Optic Outdoor Cable Anti-Rodent Steel Tape Armor Fibre Cable GYTS from wholesalers
    • Buy cheap Direct Burial 144 Core Fiber Optic Outdoor Cable Anti-Rodent Steel Tape Armor Fibre Cable GYTS from wholesalers
    • Buy cheap Direct Burial 144 Core Fiber Optic Outdoor Cable Anti-Rodent Steel Tape Armor Fibre Cable GYTS from wholesalers

    Direct Burial 144 Core Fiber Optic Outdoor Cable Anti-Rodent Steel Tape Armor Fibre Cable GYTS

    Ask Lasest Price
    Brand Name : YUANTONG
    Model Number : GYTS
    Certification : ISO,ANATEL,ROSH,TLC,CCC
    Price : usd 0.05/meter
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000km per week
    Delivery Time : within 7 working days
    • Product Details
    • Company Profile

    Direct Burial 144 Core Fiber Optic Outdoor Cable Anti-Rodent Steel Tape Armor Fibre Cable GYTS

    Multi loose tubes 144 core/fiber Outdoor Cable Anti-Rodent Steel Tape Armor optical cable GYTS
    OM1,OM2,OM3,OM4 multimode or OS1/OS2 (ITU-T G.652D) singlemode 250um fibers are positioned in a PBT loose tube. Tubes & Fillers are stranded around a steel wire or FRP central strength member into a compact and circular cable core.The Corrugated Steel Tape is longitudinally applied over the cable core. The cable is completed with Polyethylene PE jacket or LSZH.

    Features

    • Can be installed without shutting off the power
    • Light weight and small diameter reducing the load caused by ice and wind and the load on towers and backprops
    • Large span lengths and the largest span is over 1000m
    • Good performance of tensile strength and temperature

    Application

    • Long distance communication and LAN

    Technical Parameter

    Fiber Count144
    Outer Dia.(mm)13.8
    Tensile Resistance(N)Long Term600
    Short Term1500
    Crush Resistance(N/100m)Long Term300
    Short Term1000
    Mini Bending
    Radius(mm)
    Dynamic20D
    Static10D
    Attenuation(dB/Km)1310nm≤0.36
    1550nm≤0.22
    Operating temperature(℃)-40℃+60℃
    N.W.(kg/km)190

    Company Profile
    Sichuan Yuantong Communication Co., Ltd, a national key high-tech Enterprise.Our company is wholeheartedly committed to conducting in-depth research and development, and is dedicated to manufacturing a diverse range of fiber optic cables.


    Certifications
    Company has got many national approval certificates.


    Packaging & Shipping



    FAQ

    Q1:What's your best price?
    A:Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the time.
    Q2:What's your MOQ?
    A:Low MOQ, 1pc for sample checking is available.
    Q3:Can I print our own logo on the product?
    A:Yes, Please send your logo to us.
    Q4:Can you provide OEM/ODM service?
    A:Yes, we can. Please tell us the details of your requirements
    Q5:How can you guarantee the delivery time?
    A:To avoid the delay, we have built a complete and professional procedure system from production to the deliver and have rich experience.

    Expect this to be a fine start for our cooperation!
